Rectifier Regulator 12v – Half Wave

Black universal 4 pin regulator rectifier

Universal 4 pin half wave rectifier & 12V DC regulator, suitable for 50cc to 170cc engines.

Fits most 4-stroke pit bikes, monkey bikes, scooters, quad bikes, go-kart engines and more. Will work with kick or electric start engines, with or without a battery!

Combined regulator rectifier units convert the fluctuating AC voltage coming from your alternator/magneto/stator into 12 volts DC. Allowing you to run your DC electrics and charge your battery, all in one unit!

Swap out your old unit or even convert an old two part system. With just 4 wires, you can finally simplify your bikes electrics.

Want to get rid of some weight? Take out your battery and power your electrics straight from your stator coils with this complete 12V regulator rectifier.

Specifications for black 4 pin half wave regulator rectifier unit -

Type - single phase 4 pin regulator rectifier unit
Rectification - Half wave (positive half cycle)
Overall length - 68mm
Overall width - 35mm
Overall height - 20mm
Material type - Metal / aluminium
Colour - Black
Engine capacity range - 50cc to 170cc engines
Connector type - 4 pin, 6.4mm motorcycle connector pins

Wiring terminals (refer to final image):
GND   - Earth (typically a green wire)
L         - AC current in (typically a yellow wire)
AC      - AC current in (typically a yellow or white wire)
+B      - 12v-14.4v out to battery (typically a red wire)

Easy to install - no instructions required

Package includes: 1 x 4 pin regulator rectifier unit

4 Pin Regulator Rectifier is Suitable for...

Most pit bikes, Monkey bikes, Quad bikes/ATVs, Scooters, Go-karts and more....
